33798-S8
Nut (hex)-5/16"-24-pipe assy
-muffler inlet to front
resonator assy
LE
_
55
u
33798-S8
Nut (hex)-5/16"-24-pipe assy
muffler inlet R. H. -to
muffler assy
LE
55
V
33801-S8
Nut (hex)-7/16"-14-pipe assy
-muffler inlet to exhaust
manifold
LE
55
33827-S8
Nut (hex)-3/8"-16
4
LA
52-54
33827-S8
Nut (hex)-3/8"-16-muffler
inlet pipe assy to exhaust
manifold
4
LE
55
352730-S8
Stud-3/8"-16 & 3/8"-16 x
1-1/2"-inlet pipe to exhaust
manifold
4
LA, LE
52-55
LA-55246-A
Insulator (muffler inlet pipe)
1
LA
52-54
LE 5248-A
Pipe assy (muffler inlet)-L.H.
1
LE
55
23426-S8
Bolt (carriage)-3/8"-24 x
1-1/8"-pipe assy muffler
inlet front L. H. to pipe &
insulator assy-inlet rear
L. H.
1
LE
55
357625-S7
Lockwasher-7/16"-pipe assy
-muffler inlet-front L. H. to
exhaust manifold L. H.
2
LE
55
357629-S7
Lockwasher-3/8" -pipe assy
-muffler inlet-front L. H. to
pipe & insulator assy
muffler inlet rear R. H.
1
LE
55
33800-S8
Nut (hex)-3/8"-24-pipe assy
-muffler inlet-front L. H. -
to pipe and insulator assy
1
LE
55
33801-S8
Nut (hex)-7/16"-14-pipe assy
-muffler inlet front L. H. to
exhaust manifold L. H.
2
LE
55
LA-55248-B
"U" bolt (muffler inlet resonator)
-front
5
LA
53-54
LE-55248-A
"U" Bolt (muffler inlet resonator)
-front
8
LE
55
357624-S7
Lockwasher-5/16"-front
resonator to muffler
2
LA
53-54
357624-S7
Lockwasher-5/16"-inlet pipe
to front resonator
2
LA
53-54
357624-S7
Lockwasher-5/16"-pipe to
rear resonator
2
LA
53-54
33798-S8
Nut (hex)-5/16"-24-front
resonator to muffler
2
LA
53-54
33798-S8
Nut (hex)-5/16"-24-inlet pipe
front resonator
2
LA
53-54
33798-S8
Nut (hex)-5/16"-24-pipe to
rear resonator
LA
53-54
