LA 5255-A
Pipe (muffler outlet)-89-29/64" approximate
formed length
LA
5 2
LA 5255-B
Pipe (muffler outlet)-58-19/32" approximate
formed length
LA
53
LA 5255-D
Pipe (muffler outlet)-52-11/32" approximate
formed length
1
LA
54
LE 5255-A
Pipe (muffler outlet R. H. )
LE
55
LA-55255-B
Resonator assy (exhaust)-rear
LA
53-54
20327-S8
Bolt (hex-hd)-5/16"-24 x 5/8"-
bracket & insulator outlet
pipe to frame L. H.
LE
55
357624-S7
Lockwasher (special)-5/16"-
pipe muffler outlet to
resonator assy
LA
53-54
357624-S7
Lockwasher-5/16"-muffler
outlet pipe R. H. to clamp
muffler outlet-lower rear
LE
55 J
33798-S8
Nut (hex)-5/16"-24-muffler
outlet pipe R. H. to clamp
muffler outlet pipe lower
rear
LE
55
33798-S8
Nut (hex)-5/16" -24-muffler
outlet to resonator assy rear
LA
53-54
LE 5256-A
Bracket & insulator assy (muffler outlet pipe)-L. H.
LE
55
357624-S7
Lockwasher-5/16"-bracket
& insulator assy to outlet
pipe L. H. to frame
LE
55
33798-S8
Nut (hex)-5/16"-24-bracket &
insulator assy muffler outlet
pipe L. H. to frame
LE
55
LA 5259-A
Bracket & insulator assy muffler outlet pipe)-
upper front
LA
52
LA 5259-B
Bracket & insulator assy muffler to rear resonator
pipe)
LA
53-54
LE 5259-A
Bracket & insulator assy (muffler outlet pipe)-upper
front-L. H.
LE
55
24387-S7
Bolt (hex-hd)-5/16"-24 x 1"-
bracket & insulatoY- to frame
LA
52-54
357624-S7
Lockwasher-5/16"
LA
52-54
33798-S8
Nut (hex head)-5/16"-24
2
LA
53-54
34443-S7-8
Nut (lock)-5/16"-24
LA
52
356329-S
Washer (rectangular)-1"
-
15/64"
LA
52
