LE-55259-A
Pipe (muffler outlet)-L.H.
LE
55
33798-S8
Nut (hex)-5/16"-24-muffler
outlet pipe L. H. & resonator
to muffler outlet pipe brkt.
& insulator assy L. H.
LE
55
33798-S8
Nut (hex)-5/16"-24 muffler
outlet pipe L. H. to clamp
-muffler outlet pipe lower
rear
LE
55
33798-S8
Nut (hex)-5/16"-24-resonator
assy to muffler outlet pipe
bracket to insulator assy
R. H.
LE
55
357624-S7
Lockwasher-5/16"-muffler
outlet pipe to clamp-muffler
outlet pipe lower rear
LE
55
357624-S7
Lockwasher-5/16"-muffler
outlet pipe L. H. -resonator
assy to muffler outlet pipe
bracket & insulator assy
L. H.
LE
55
LA 5261-B
Bracket & insulator assy ("S" type)-outlet pipe)-rear
LA
52-53
LA 5261-D
Bracket & insulator assy ("U" type)-outlet pipe-)-rear
LA
54
LE 5261-A
Bracket & insulator assy (muffler outlet pipe)-rear
LE
55
20327-S7-8
Bolt (hex head)-5/16"-24 x
3/4"-bracket & insulator to
frame
LA, LE
52-55
357624-S7
Lockwasher-5/16"-brkt. &
insulator assy-muffler outlet
pipe rear to exhaust
extension assy R. H. & L. H.
LA, LE
52-55
33798-S8
Nut (hex)-5/16"-24-brkt. &
insulator assy to muffler
outlet pipe rear
LA, LE
52-55
44724-S8
Washer (flat)-5/16"-bracket
& insulator assy to muffler
outlet pipe rear to exhaust
extension R. H. & L. H.
LE
55
LA 5263-D
Extension (muffler outlet pipe)-Chrome-10" long
LA
54
LA 5265-A
Clamp (muffler outlet pipe)-lower front
LA
52
LA 5265-B
Clamp (muffler to rear resonator pipe)
LA
53-54
LE 5265-A
Clamp (muffler outlet pipe lower front)
LE
55
20387-S8
Bolt (hex hd)-5/16"-24 x 1"-
muffler outlet pipe lower
front to bracket & insulator
assy upper front R. H.
LE
55
23441-S7
Bolt (rd-hd)-3/8"-24 x 1-1/4"-
clamp to bracket
52
24387-S7
Bolt (hex-hd)-5/16"-24 x "-
bracket to clamp
LA
53-54
357629-S7
Lockwasher-3/8"
LA
52
33800-S8
Nut (hex)-3/8"-24
LA
52
