EAD 5267-C
Pipe assy (exhaust manifold crossover)-one (1)
piece construction
LA
52
EAD 5267-D
Pipe assy (exhaust manifold crossover)-two (2)
piece construction
LA
53-54
EAD 5267-F
Pipe assy (exhaust manifold crossover)-also may
be used on 52-53 by adding EAD-9685-C valve,
EAD-9430-D manifold, & (4) 354055-S studs
LA
54
EAD 5267-G
Pipe assy (exhaust manifold crossover)
LA60-73
54
OEAD-55267-C Pipe & thermostat valve assy
(exhaust manifold crossover)
LA60-73
53
EAD-55272-A Shield assy (exhaust crossover
pipe heat)-4" long x 2-31/32"
wide
LA60-73
53-54
B-8287-A
Clamp assy-to attach crossover
pipe heat shield
LA60-73
53
34806-S7
Lockwasher-5/16"-crossover
pipe to exhaust manifold
LA
52-54
33825-S7
Nut (hex)-5/16"-18-crossover
pipe to exhaust manifold
LA. LE
52-55
352719-S8
Stud-5/16"-18 & 5/16"-18 x
1-1/4"-crossover pipe to
exhaust manifold
LA. LE
52-55
0354055-S
Stud-5/16"-18-18 x 2-1/16"
LA60-73, LE60-73
54-55
LA 5273-B
Bracket & insulator assy (muffler outlet pipe)-
intermediate
LA
52
24327-S8
Bolt (hex-hd)-5/16"-24 x 5/8"
-bracket to crossmember
LA
52
357624-S7
Lockwasher-5/16"
LA
52
357252-S2
Nut (cage)-5/16"-24
LA
52
LE-55279-A
Pipe (muffler to rear resonator
-L. H.
LE
55
357624-S7
Lockwasher-5/16"-pipe
muffler to rear resonator
LE
55
33798-S8
Nut (hex)-5/16"-24-pipe
muffler to rear resonator
LE
55
BS-55286-A
Deflector (resonator heat front
LA60-73, LE60-73
54-55
BS-55293-A
Deflector assy (muffler heat)
(make "A" from BS-55293-B by
adding BS-55296-A)
LA73, LE73
54-55
BS-55293-B
Deflector assy (muffler heat)
LA60, LE60
54-55
BS-55296-A
Spacer (muffler heat deflector to
floor)
LA73 LE73
54-55
LE 5280-A
Clamp (muffler outlet pipe lower rear)
LE
55
20387-S8
Bolt (hex hd)-5/16"-24 x 1"-
clamp muffler outlet pipe
rear to bracket & insulator
LE
55
34443-S8
Nut (hex)-5/16"-24-clamp-
muffler outlet pipe-lower to
bracket & insulator assy
LE
55
LE 5282-A
"U" Bolt (resonator rear)
LE
55

v used with Air Conditioning - Refer to Air Conditioning Group
