OM 5713-B
NS Shackle & stud assy ( rear spring)-serviced in
HCK-5630-A Kit
LA, LE
52-55
357629-S7
Lockwasher special)
LA, LE
52-55
33800-S8
Nut (hex)-3/8"-24
2
LA, LE
52-55
34671-S8
Nut (hex)-7/16"-20
LA, LE
54-55
8M 5719
Bushing (rear spring shackle)-also serviced in
HCK-5630-A Kit
12
LA. LE
52-55

REAR SPRING OUTER CLAMP CHART
PART NUMBER
C
L
A
A
B
C
D
E
NO
MODEL
t9 AR
8A 5724-D
1-29/32"
2-3/16"
5/8"
3/16"
9/32"
4
LA, LE
52-55
OM 5724-B
1-3/16"
2-3/16"
5/8"
3/32"
9/32"
4
L A, LE
52-55
OM 5724-D
2-9/16"
2-3/16"
5/8"
3/32"
9/32"
2
LA, LE
52-55
OM 5724-E
2-15/16"
2-3/16"
5/8"
3/32"
9/32"
2
LA, LE
52-55
PART NUMBER
C
L
PART NAME
MODEL
YEAR
19
21481-S2
Bolt (hex-hd)-1/4""-20 x 1-3/4""
-rear clamp to spring assy
6
LA, LE
52-55
34805-S8
Lockwasher-1/4""
6
LA, LE
52-55
33795-S7
Nut (hex)-1/4"-20
6
LA, LE
52-55
LA 5770-C
1
LA, LE
52-55
34671-S8
Nut (hex)-7/16"-20
2
LA, LE
54-55
LA 5775-C
Hanger assembly (rear spring)-front-L. H.
1
LA, LE
52-55
357625-57
Lockwasher-7/16"
2
LA, LE
52-55
33802-S8
Nut (hex)-7/16""-20-hanger to
rear spring
2
LA. LE
52-55
8M 5780-A
NS Pin assy (rear spring front hanger)-serviced in
HCK-5630-A Kit
LA. LE
52-55
MA 5783-A
Bumper assembly (rear axle)
2
LA, LE
52-55
MA-55712-A
Bumper assy (rear spring)-with
2" long x 2-19/64" wide rubber
bumper
2
LA, LE
52-55
40156-S8
Screw (hex-hd self tapping)-
5/16"-18 x 5/8"-bumper to
frame
12
LA, LE
52-55
LA 5798-B
_ Plate (rear spring ""UP' bolt)
2
LA, LE
52-55
