EAD 6020-A
Gasket (cylinder front cover)-also serviced in
HCK-6059-A Kit
T
LA
52-53
EAD 6020-B
Gasket (cylinder front cover)-also serviced in
HEK-6008-D, HFK-6008-A, HCK-6059-B Kits
LA, LE
J
54-55
EAD 6023-C
Pointer (timing)
1
LA, LE
52-55
OEAD 6023-D
Pointer (timing)
1
LA60-73
54
021549-S8
Bolt (hex-hd)-3/8"-16 x 2-3/4"
-pointer to compressor
bracket to cylinder block
1
LA60-73
54
045528-S8
Bolt (hex-hd)-3/8"-16 x 2-3/4',
-pointer to compressor
bracket to cylinder cover to
block
1
LA60-73
52-54
18 6026-A
Plug (tapered thread)-1/4"-18
1or3
LA
52-54
EAD-66028-A
Plug assy (cylinder block oil line)-
front-1/4"-18
2
LA,LE
52-55
352996-S100 Plug (cylinder block oil pipe)-
rear
as
reqd
LA, LE
52-55
