EAD 6059-B
Cover (cylinder front)-use with EAD-6010-F
LA, LE
54-55
20514-S7
Bolt (hex-hd)-3/8"-16 x 1-7/8"
-cover to cylinder block
LA, LE
52-55
20428-S8
Bolt (hex-hd)-3/8"-16 x 1-1/4"
-cover to cylinder block
LA
52-54
34807-S8
Lockwasher-3/8"-cover to
cylinder block
LA, LE
52-55
HCK 6059-A
Kit (front cylinder cover gasket)-consists of the
following
(1) EAD-6020-A Gasket (1) EAA-6700-B Seal
(1) EAD-8507-A Gasket
LA
52-53
HCK 6059-B
Kit (front cylinder cover gasket)-consists of the
following
(1) EAD-6020-B Gasket (1) EAA-6700-B Seal
(1) EAD-8507-A Gasket
LA, LE
54-55
B2Q 6061-A
Dowel (cyl. head to cyl. block) -®EAD-66061-A
LA, LE
52-55
EAD 6065-C
Bolt (cylinder head)-1/2"-13 x 2-1/2"-alternate
with EAD-6065-D
10
LA, LE
52-55
EAD 6065-D
Bolt (cylinder head)-1/2"-13 x 2-5/8"-alternate
with EAD-6065-C
10
LA, LE
52-55
8N 6065-A
Bolt (special)-7/16"-14 to attach trans. & converter
to engine assy
LE
55
356474-S18
Washer (flat)-1/2•'-used with
EAD-6065-D
10
LA, LE
52-55
EAD 6066-C
Bolt (cylinder head)-1/2"-13 x 4-1/4"-alternate
with EAD-6066-D
10
LA. LE
52-55
EAD 6066-D
Bolt (cylinder head)-1/2"-13 x 4-3/8"-alternate
with EAD-6066- C
10
LA, LE
52-55
LA 6068-A
Insulator assembly (engine rear mount)
LA, LE
52-55
LA-66070-A
Insulator assy (engine rear mount
rebound)
LA, LE
52-55
HCK 6079-D
Kit (valve gasket set)-consists of the following
(2) EAD-6051-B Gasket (1) EAD-6521-A Gasket
(6) EAD-6570-C Seal
(16) EAA-6571-A Seal
(2) EAD-6584-B Gasket (1) EAD-8255-A Gasket
(2) EAD-8563-B Gasket (1) EAD-8590-B Gasket
(2) EAD-9441-B Gasket (2) B2Q-9450-A Gasket
LA
52-54
HCK 6079-E
Kit (engine assy gasket upper)-consists of the
following
(2) EAD-6051-B Gasket (1) EAD-6521-A Gasket
(6) B4A-6570-A Seal
(16) EAA-6571-A Seal
(2) EAD-6584-B Gasket (1) EAD-8255-A Gasket
(1) EAD-8563-B Gasket (1) B4Q-8590-A Gasket
(2) EAD-9441-B Gasket (2) B2Q-9450-A Gasket
LA
54
HFK 6079-A
Kit (engine assy gasket upper)-consists of the
following
(2) EBJ-6051-C Gasket (1) EAD-6521-A Gasket
(4) B4A-6570-A Seal
(16) EAA-6571-C Seal
(2) EAD-6584-B Gasket (1) EAD-8255-A Gasket
(1) EAD-8563-B Gasket (1) EAD-8590-B Gasket
(2) B2Q-9450-A Gasket (2) EAD-9441-B Gasket
LE
55
