9
PART NUMBER
C
A
PART NAME
s
'D
MODEL
YEAR
19____
HACK 6600-B
Kit (oil pump gasket)-consists of the following
(1) EAD-6619-A Gasket (1) B4A-6648-A Gasket
(1) B4Q-6659-A Gasket (1) EAD-6668-B Ferrule
(1) 8EL-6669 Gasket
1
LA, LE
54-55
EAD 6608-A
Gear assy (oil pump drive)
LA
52-54
B4A 6608-B
Gear assy (oil pump drive)- ®EAD-6608-B
1
LA
54
B5A 6608-A
Gear assy (oil pump drive)-CG-6608-A
LE
55
EAD 6610-A
Gear (oil pump driven)-1-13/32" long - 7 teeth
LA, LE
52-55
EAD 6615-B
Cover assembly (oil pump screen)
LA, LE
52-55
42709-S8
Screw & L/W assy (fill-hd)-
5/16"-24 x 3/8"-cover to oil
pan
LA, LE
52-55
EAD 6616-A
Cover (oil pump)
LA, LE
52-55
42846-S8
Bolt (hex-hd)-5/16"-18 x 7/8"-
cover to oil pump
4
LA, LE
52-55
34806-S7
Lockwasher-5/16"-cover to oil
pump
LA, LE
52-55
EAD 6619-A
Gasket (oil pump cover)-also serviced in
HEK-6008-D HFK-6008-A, HCK-6600-A & B Kits
LA, LE
52-55
41A 6623
Screen assembly (oil pump)
LA, LE
52-55
EAD 6625-B
Gasket (oil pump inlet tube flange)-inner-2-1/4" x
2-1/32" x 11/32" thick-also serviced in
HEK-6008-D & HCK-6675-A & B Kits
LA
52-54
134A 6625-A
Gasket (oil pump inlet flange)-EAD-6625-C
-also serviced in HFK-6008-A. HCK-6675-C and
HEK-6008-D Kits
LE
55
B2Q 6627-A
Shaft assy (oil pump intermediate)- ®EAD- 66627-A
1
LA
52-54
B5Q 6627-A
Shaft assy (oil pump intermediate) -®EBB-66627-A
1
LE
55
EAD 6628-A
Spring (oil pump screen)-5-1/2" long
1
LA, LE
52-55
EAD 6639-A
Tube assembly (oil pan to oil pump)
1
LA
52
EAD 6639-B
Tube assembly (oil pan to oil pump)
1
LA, LE
52-55
42712-S8
Screw & L/W assy-5/16"-24 x
3/4"-tube to oil pan
3
LA, LE
_
52-55
B2Q 6643-B
Seal (oil pump inlet tube)-®EAD-66643-B-also
serviced in HCK-6675-A & B Kits
1
LA
52-54
B4A 6643-A
Seal (oil pump inlet tube)-®EAD-66643-C-also
serviced in HFK-6008-A, HEK-6008-D &
HCK-6675-C Kits
1
LA, LE
54-55
EAD 6648-B
Gasket (oil pan to oil pump tube flange)-triangular
shaped with (3) 11/32" holes & (1) 1" hole-also
serviced in HEK-6008-D, HCK-6600-A and
HCK-6675-A & B Kits
1
LA
52-54
B4A 6648-A
Gasket (oil pan to oil pump tube flange)-
+EAD-6648-C-also serviced in HCK-6600-B,
HFK-6008-A & HCK-6675-C Kits
LA, LE
54-55
B4Q 6659-A
Gasket (oil pump to block)-®EBB-6659-A-also
serviced in HEK-6008-D, HCK-6600-B and
HFK-6008-A Kits
1
LA, LE
52-55
EAA 6666-A
Nut (hex)-5/8"-18 x 1/2"-oil relief valve
1
LA, LE
52-55
EAD 6668-B
Ferrule assy (oil pump inlet tube)-29/32" 0. D. x
5/8" I. D. x 15/32" thick-also serviced in
HEK-6008-D, HFK-6008-A, HCK-6600-A & B Kits
1
LA, LE
52-55
8EL 6669
Gasket (oil pump relief valve)-41/64" I. D. x 7/8"
0. D. x 3/64" thick-also serviced in
HEK-6008-D, HFK-6008-A, HCK-6600-A & B Kits
1
LA, LE
52-55
EAD 6670-A
Spring (oil pump relief valve)-3/8"diameter x
2-3/16" overall length-22 coils also serviced in
HCK-6600-A & HFK-6600-A Kits
1
LA, LE
52-55
EAD 6673-A
Nut (oil pump inlet tube)-compression-1"-18
1
LA, LE
52-55
