LA-7874-B
Kit (transmission pressure regulator
plug and
gaskets)-consists of the following
(1) OL-77355 Seal
(1) OL-77382 Gasket
(1)
Plug assy
(1)
Plug (reverse booster)
(1)
Plug (T. V.) (1) LA-7893-A Spring
LA-7893-A
Spring (regulator valve dampener)-also
serviced
in LA-7874-A & B Kits
PMC-7908-A
Impeller assembly (converter)
*LA-7910-A
Cover assy (transmission torus)
*8L-7912
Torus assy (transmission driven)
*8L-7914
Torus assy (transmission driving)
B5A-7915-A
Hub (converter impeller)- PMB-7915-A
356748-S
Bolt (hex-hd)-1/4"-20 x 5/8"-impeller
hub to impeller housing
34805-S8
Lockwasher-1/4"-hub to impeller
housing
*1L-7916-A
Valve (transmission torus check)
1P-7916-A
Gasket (converter impeller hub)
8L-7917
Snap ring (torus retaining)
*LA-7919-A
Lever (transmission throttle control
outer)
*24385-S2
Bolt (hex-hd)-1/4'•-28 x 1"-throttle
control
lever to transmission manual shaft
* Used with but not part of basic number
7003 assembly
