*1P-7945-A
Snap ring (converter stator clutch)
*1P-7946-A
Race (converter stator clutch)-inner
*1P-7947-B
Race (converter stator clutch)-outer
*PMC-7950-A Cover assembly (converter)
357916-S
Plug (hex-hd pipe)-1/8"-27-drain
1P-7962-A
Washer (converter thrust)-1-1/4" I. D. x
2-7/16" O. D. x 1/16" thick
PMC-7963-A
"O" Ring (converter cover)
1P-7964-D
Bolt (converter cover to impeller housing)
357919-S
Nut (hex)-5/16"-24-attach impeller to
converter cover
PMC-7975-A
Housing assy (converter)
20310-S8
Bolt (hex-hd)-5/16"-18 x 1/2"-cover to
converter housing
20450-S Bolt (hex-hd)-7/16"-14 x 1-3/8" -converter
housing to transmission case
34848-S8
Lockwasher-7/16" -converter housing to
transmission case
34806-S7
Lockwasher-5/16"-use with 20310-S8
LE-7985-B
Cover assembly (converter housing)
PMB-7993-B
Screen assy (converter housing air intake)
LE-7995-B
Duct (torque converter air intake)
PMC-17285-A
Gear (speedometer drive)
353078-S
Ball (steel)-1/4" dia. -to key speedometer
gear to output shaft
$LA-77005-A
Breather and indicator assy (trans. oil)
*8L-77008
Bolt (hex-hd)-1/2"-13 x 1-1/2"-flywheel housing
to transmission
*34809-S8
Lockwasher-1/2"-flywheel housing to trans.
8L-77011
Pan assembly (transmission oil)
8L-77014
Gasket (transmission oil pan) -also serviced
in HAK-7086-B Kit
20310-S8
Bolt (hex-hd)-5/16"-18 x 1/2"-oil pan to
transmission case
34941-S7
Lockwasher (external tooth)-5/16"
8L-77016
Screen assembly (transmission oil pump intake)-
6-3/4" x 6-3/4"
LA-77016-A
Screen assy (transmission oil pump intake)-
6-43/64" x 4-15/16"
8L-77017
Gear and shaft assy (transmission main drive)
8L-77019
Indicator assy (transmission oil level)-located
under front compartment floor pan
8L-77020
Tube (transmission oil filler)-1-3/16" 0. D. x
1-5/8" long-located under front compartment
floor pan
*LA-77020-A
Tube assy (trans. oil filler)-approx. 22-1/4"
formed length-used with LA- 77626- A- located
under hood compartment at right front of dash
*LE-77020-A
Tube assy (transmission oil filler)
