*LA-77021-A
Clamp (transmission oil filler tube)-use
with
LA-77020-A
8L-77022
Gasket (transmission case front cover)-also
serviced in HAK-7086-B Kit
LA-77022-A
"0" Ring (front pump seal)-Rubber
8L-77027
Sleeve assy (transmission oil supply
to clutches)
20246-S8
Bolt (hex-hd)-7/16"-14 x 2-1/2"-center
bearing cap to case
8L-77031
Plate (transmission center bearing cap
lock)
8L-77032-A
Washer (transmission main shaft thrust)-rear-
. 055"/. 059" thick
8L-77032-B
Washer (transmission main shaft thrust)-rear-
. 063"/. 067" thick
8L-77032-C
Washer (transmission main shaft thrust)-rear-
.071"/. 075" thick
8L-77032-D
Washer (transmission main shaft thrust)-rear-
.079"/. 083" thick
8L-77032-E
Washer (transmission main shaft thrust)-rear-
.087"/. 091" thick
8L-77032-F
Washer (transmission main shaft thrust)-rear-
. 095"/. 099" thick
8L-77032-G
Washer (transmission main shaft thrust)-rear-
. 103"/. 107" thick
8L-77032-H
Washer (transmission main shaft thrust)-rear-
111"/. 115" thick
PMC-77059-A
Shaft & ring gear assy (output)
74144-S Key (woodruff)-No. 5-rear pump
driving
gear to output shaft
1L-77061-A
Shaft assy (trans. output)-with approx.
450
spline end-integral speedometer driving
gear
B5A-77066-A
Washer (trans. output shaft thrust)-rear-
Bronze & Steel backed- 1/16"
thick
(E, PMB-77066-A
B5A-77067-J
Washer (trans. output shaft thrust)-front
Bronze- 061"/.063" thick-(DPMB-77067-A
B5A-77067-K
Washer (trans. output shaft thrust)-front
Bronze- 067"/.069" thick-BPMB-77067-B
B5A-77067-L
Washer (trans. output shaft thrust)-front
Bronze- 074"/.076" thick-TPMB-77067-C
B5A-77067-M
Washer (trans. output shaft thrust)-front
Bronze- 081"/.083" thick-DPMB-77067-D
8L-77069
Snap Ring (transmission output shaft
center
bearing retainer)
8L-77072
Gear (rear internal)-before trans.
#L51-9462
1L-77072-A
Gear (rear internal)-starting with
trans.
#L51-9462
8L-77077
Screw (fillister head)-Nd. 10-24 x
1"-rear
internal gear to rear drum
8L-77126
Screw & washer assy (fillister
hd)-No. 10-24
x 1"-front valve body to inner
valve body
8L-77126
Screw & washer assy (fillister
hd)-No. 10-24
x 1"-front valve body cover plate
