8L-77189
Washer (trans. front clutch drum rear
thrust)-
Bronze-grooved-1-3/8" I. D. x 1-29/32"
O. D.
x 3/32" thick
8L-77190
Washer (trans. front planetary assy
front thrust)-
Bronze-1-13/32" I. D. x 1-53/64"
O. D. x
3/32" thick
B5S-77190-A
Support assy (trans. planetary) -+PMB-77190
-A
351487-S
Lockwasher (external tooth)-3/8"-support
to transmission case
1P-77194-A
Screw (hex-hd)-3/8"-16 x 29/32"-with
tapered
end-trans. planetary support locking
1L-77201
Valve assembly (transmission oil control)
LA-77201-A
Valve assembly (transmission oil control)
LA-77201-B
Valve assembly (transmission oil control)
tLA-77201-C
Valve assembly (transmission oil control)
-stamped "4" at end of throttle
lever
LA-77201-E
Valve assembly (transmission oil control)-
stamped "12" at end of 8L-77284
21497-S Bolt (hex-hd)-1/41,-20 x 2"-control
valve assy
to transmission case
34803-S7
Lockwasher-No. 10-use with 356746 &
356747-S
34940-S2
Lockwasher (external tooth)-1/4- control
valve assembly to transmission case
