351991-S
Screw & washer assy (fillister head)-No.
10-24
x 1-1/4"-front valve body to inner
valve body
351992-S
Screw & washer assy (fillister head)-No.
10-24
x 1-3/8"-front valve body to inner
valve body
352978-S
Screw & washer assy (fillister head)-No.
10-24
x 1-1/4"-front valve body to inner
valve body
353616-S
Screw & lockwasher assy (fillister
head)-
No. 10-24 x 3/8"
(3) Outer valve body frt. plate to outer
valve body
(3) Front valve body plate to front
valve
356746-S
Screw (fill-hd)-No. 10-24 x 3/4"-retainer
to
outer valve body
356746-S
Screw (fillister head)-No. 10-24 x 3/4"-valve
body rear cover to inner valve body
356747-S
Screw (fillister head)-No. 10-24 x
1-valve
body rear cover to. inner valve body
356747-S
Screw (fillister head)-No. 10-24 x
1"-front
valve body to inner valve body
358496-S
Screw & washer assy (flat head)-No.
10-24 x
7/16"-detent plug plate
358497-S
Screw & washer assy (fill-hd)-No.
10-24 x
5/8--
358502-S
Screw & washer assy (fill-hd)-No.
10-24 x
3/4"-valve body rear cover to inner
valve
body
358502-S
Screw & washer assy (fill-hd)-No.
10-24 x
3/4"-retainer detent plunger to
outer valve
body
358504-S
Screw & washer assy (fill-hd)-No.
10-24 x 1"-
rear valve body cover to inner valve
body
LA-77202-A
Retainer (trans. control valve detent
plunger)
LA-77203-A
Spring (transmission reverse exhaust
valve)
LA-77203-A
Spring (trans. control valve throttle
oil ball)
357146-S
Ball-7/32" dia. -transmission control
valve
LA-77206-A
Plug (transmission control timing valve)
LA-77207-A
Pin (transmission control valve plug
retainer) -
5/64" dia. x 15/16" long
1L-77208-A
Spacer (trans. control valve detent
plunger ret. )-
1-1/4', wide x 1-3/16" long-with
(6) holes
8L-77211
Kit (transmission throttle shaft repair)-consists
of the following
(1) 72187-S7 Pin
(1) 8L-77223
Seal
(6) 351543-S Washer
HEK-77211-B
Kit (transmission throttle shaft repair)-consists
of the following
(1) 8L-77223 Seal
(1) LA-77223-A Seal
(1) 72187-S
Pin
(2) 351543-S
Washer
8L-77223
Oil seal (trans. throttle control shaft)-serviced
in HEK-77211-B Kit
LA-77223-A
"0" Ring (trans. throttle control
shaft oil seal)-
serviced in HEK-77211-B Kit
