356414-S
Washer (flat)-21/64" I. D. -use with
parking
pawl toggle lever pin
1P-77319-A
Pin (trans. parking pawl toggle lever
support)-
3/8" dia. x 1-3/4" o/all length-special
head
8L-77320
Plate (transmission oil pump inlet pipe
bolt)
LA-77320-A
Retainer (transmission blocker piston
pin)
8L-77321
Pipe assy (trans. front oil pump inlet)-with
flange
24324-S7
Bolt (hex-hd)-1/4"-20 x 5/8"-intake
pipe to
front pump
LA-77321-A
Pipe (transmission front oil pump inlet)-without
flange
1P-77322-A
Rod (trans. parking pawl torsion lever)-1/4"
dia.
x 2-15/16" o/all length-cotter pin
hole at
each end
72000-S7
Cotter pin-1/16" x 3/8"-retains
parking
pawl link rod
1P-77323-A
Retainer (trans. parking pawl toggle
return spring)
-5/16" I. D. x 27/64" O. D.
x 7/16" long
1L-77325-B
Spring (transmission parking blocker
piston)-
11/32" 0. D. x 1-1/32" approx.
free length
LA-77325-A
Spring (transmission parking blocker
piston)-
7/16" O. D. x 1-1/16" approx.
free length
72886-S8
Pin (straight)3/32" x 1"-to
retain spring to
parking blocker
