73281-S
Pin (straight chamfer)-3/32" x 13/16"
352979-S
Screw (fillister head)-1/4"-20 x
1"-pump
body to cover
44722-S8
Washer (flat)-5/16"
LA-77332-A
Valve (transmission front oil pump relief)
1L-77333-A
Valve (trans. front pump by pass)-9/16"
O. D.
x 15/32" I. D. x 5/8" long
8L-77334
Seal (transmission front cover oil)
8L-77336
Washer (trans. front cover to pump screw)-
Copper-17/64" I. D. x3/8"0.D.-1/3211
thick
also serviced in HBK-77330-A Kit
OL-77337
Gear assembly (transmission front drive)
LA-77337-A
Gear assembly (transmission front drive)
1L-77339-A
Bolt (trans. front oil pump body to
cover)-
serviced in HBK-77330-A Kit
8L-77340
Ring (trans. front oil pump seal)-2-3/8"
O. D.
x 3/32" thick
LA-77340-A
Ring (trans. front oil pump seal)-2-3/8"
O. D.
x 1/8" thick
8L-77342
Washer (trans. front pump locating)-Steel-21/64"
I. D. x 1/2" O. D. x 3/321, thick
8L-77346
Gasket (transmission front pump intake
pipe)-
also serviced in HAK-7086-B Kit
8L-77347
Key (Woodruff)-. 188//. 189" thick-transmission
front pump drive
8L-77348
Pipe (transmission front oil pump delivery)-
3-15/161, overall length
LA-77349-A
Spring (transmission front oil pump
relief valve)
