8L-77351
Pump assembly (transmission rear oil)
24366-S8
Bolt (hex-head)-5/16"-18 x 7/8"-rear pump
to transmission case
24388-S8
Bolt (hex-head)-3/8"-16 x 1"-rear pump to
transmission case
34806-S7
Lockwasher-5/16"
72869-S Pin (straight)-3/161' x 7/8"-rear oil pump
driven gear to shaft
8L-77353
Cover (transmission rear oil pump)
