2
CHASSIS PARTS CATALOGUE
Wheels, Hub and Drums---Continued
Washer (front hub bearing retainer)-3/4"
I. D. x
1-13/16" 0. D. x 3/32" thick,
with lug for keyway
2
LA, LE
52-55
Cone and roller assembly (front wheel)-inner
2
LA. LE
52-55
Cup (front wheel bearing)-inner-2-23/32"
0. D.
-
2
LA, LE
52-55
Cone and roller assembly (front wheel)-outer
2
LA, LE
52-55
Cup (front wheel bearing)-outer-1-15/16"
0. D.
2
LA, LE
52-55
-B
Bearing (rear wheel)-1-17/32" I.
D. x 3-5/32" 0. D.
-spare wheel clamps
2
LA, LE
52-55
BC 1446-A
Plate (spare wheel mounting)
1
LA
52
BD 1446-A
Plate (spare wheel mounting)
1
LA, LE
53-55
BD 1448-C
Bolt (spare wheel mounting}-3/8"-16-approximate)
7-3/4" long-with bend
1
LA
52
BD 1448-D
Bolt (spare wheel mounting)-3/8"-16-approximate)
8" long-without bend
1
LA, LE
53-55
BD- 7347076-A Bracket (spare wheel mounting}
1
LA
52
1
LA, LE
53-55
73889-S7 Pin (clevis)-3/8" x 7/8"-bolt
to mounting bracket
1
LA, LE
52-55
352358-5 Pin (self locking)-1" long-bolt
to mounting bracket
1
LA, LE
_
52-55
__
44728-S8 Washer (flat)-3/8"-bolt
to
mounting bracket
2
LA, LE
52-55
BA 1457-A
Nut (wing)-spare wheel mounting bolt-3/8"-16
1
LA, LE
52-55
Service Brakes
HACA-19542-A Fluid (brake)-heavy duty-pint
as
LA, LE
52-55
container
req
__
HACA-19542-B Fluid (brake)-heavy duty-gallon
as
LA, LE
52-55
container
req
HACA-19542-E Fluid (brake)-heavy duty-5
gal.
as
LA, LE
52-55
container
read
HCK 2001-A
Kit (front brake shoe & lining)-Standard-Axle
Set-
1
LA
52-53
consists of the following
(2) LA-2018-B Shoe & lining-front-primary
(2) LA-2019-8 Shoe & lining-front-secondary
HCK 2001-B
Kit (front brake shoe 8i lining)-. 030
0/S-Axle Set-
1
LA
52-53
consists of the followine
(2) LA-2018-C Shoe & lining-front-primary
(2) LA-2019-C Shoe & lining-front-secondary
HEK 2001-A
Kit (front brake shoe & lining)-Standard-Axle
Set-
1
LA, LE
54-55
consists of the following
(2) LA-2018-E Shoe & lining-front-primary
(2} LA-2019-H Shoe & lining-front-secondary
HEK 2001-B
Kit (front brake shoe & lining)-.
030 0/S-Axle Set-
1
LA, LE
54-55
consists of the following
(2) LA-2018-F Shoe &lining-front-primary
(2) LA-2019-J Shoe & lining-front-secondary
