HEK 2007-B
Kit (front brake lining)-. 030 0/S-Axle
Set-consists
1
LA, LE
54-55
of the following
(2) LA-2021-G Lining-front-primary
(2) LA-2022-G Lining-front-secondary
(44) 351939-S Rivet
HCK-22009-B Kit (rear brake spring repair)-
1
LA
52-53
consists of the following
(4) SM-2035 Spring (8) 6H-2066 Cup
(4) H-2068 Spring (4) 8A-2069-A Pin
(2) H-2092 Plate-alternate with 8A-2092
(2) 8A-2092 Plate-alternate with H-2092
HCK-22009-C Kit (front brake spring repair)-
1
LA
52-53
consists of the following
(4} 8M-2035 Spring (8) 6H-2066 Cup
(4) H-2068 Spring (4) LA-2069-A Pin
(2} H-2092 Plate-alternate with 8A-2092
(2) 8A-2092 Plate-alternate with H-2092
HEK-22009-A Kit (brake spring repair)-complete
1
LA, LE
54-55
car set-consists of the
following
(8) 96H-2036 Spring (16) 6H-2066 Cup
(8} H-2068 Spring (4) 8L-2069 Pin
(4) LA-2069-A Pin
(4) H-2092 Plate-alternate with 8A-2092
(4) 8A-2092 Plate-alternate with H-2092
LA 2012-A
Plate assembly (front wheel brake backing)
2
LA
52-53
LA 2012-C
Plate assembly (front wheel brake backing)-R.
H.
1
LA, LE
54-55
LA 2013-C
Plate assembly (front wheel brake backing)-L.
H.
1
LA, LE
54-55
351768-58 Bolt (hex-hd)-7/16"-20
x
4
LA
52-54
1-19/64"-to spindle-upper
_
357164-SS Bolt (hex-hd)-1/2"-20 x
4
LA
52-54
2-13/32"-to spindle-lower
72035-57-8 Cotter Pin-1/g' x 1"-lower
4
LA
52-54
spindle
357625-57 Lockwasher-7/16"
4
LA
52-54
34032-57 Nut (castle)-1/2"-20-lower
4
LA
52-54
spindle
34671-SS Nut (hex)-7/16"-20-plate
to
4
LA
52-54
spindle-upper
LA 2018-B N
Shoe & lining (front)-primary-std.
-serviced in
2
LA
52-53
HCK-2001-A Kit
-
LA 2018-C N
Shoe & lining (front}-primary-. 030
0/S-serviced
2
LA
52-53
HCK-2001-B Kit
LA 2018-E N
Shoe & lining (front)-primary-std.
-serviced in
2
LA, LE
54-55
HEK-2001-A Kit
LA 2018-F td
Shoe & lining (front)-primary-. 030
0/S-serviced
2
LA, LE
54-55
in HEK-2001-B Kit
OM 2019-B N Shoe & lining (rear)-secondary-std.
-serviced in
2
LA
52-53
HCK-2200-A Kit
MA 2019-C N Shoe & lining (rear)-secondary-.
030 O/S-serviced
2
LA
52-53
in HCK-2200-B Kit
LA 2019-B N
Shoe & lining (front)-secondary-std.
-serviced in
2
LA
52-53
HCK-2001-A
