IAB-2478-A
Shaft (brake pedal)-7/16"-20 x
LA, LE
52-55
$34808-S8
Lockwasher-7/16"
LA, LE
52-55
X33802-58
Nut (hex)-7/16"-20
LA, LE
52-55
LA-2482-A
Shaft (brake master cylinder
operating lever)-3/8"-24 x
2-17/32" long
LA
53
LA-2482-B
Shaft (brake master cylinder
operating lever)-3/8"-24 x 2
11/32" long
LA
54
LE-2482-A
Shaft (brake master cylinder
operating lever)-3/8"-24 x
2-11/32" long
LE
55
351022-S2
Locknut (hex)-3/8"-24-to
retain shaft
LA, LE
53-55
NS TFAF-2493-A Gasket (brake booster end plate)-
1-11/32" 1. D. x 1-19/32" 0. D.
-serviced in HDK-22160-B Kit
1
LA, LE
53-55
LA-2514-A
Lever assy (brake master cyl.
operating)
LA
53
LA-2514-B
Lever assy (brake master cyl.
operating)
LA
54
LE-2514-A
Lever asst' (brake master cyl.
operating )
LE
55
352601-S8
Bolt (hex-hd)-5/16"-24 x 1-
1/16"-operating lever to
booster assy
LA, LE
53-55
357624-S7
Lockwasher (special)-5/16"-
operating lever to power
unit
1
LA, LE
53-55
352602-S8
Pin (clevis)-3/8" x 1-1/16" -
operating lever to pedal
assy
LA, LE
53-55
72035-S7-8
Cotter pin-1/8" x 1"
LA, LE
53-55
356363-57
Washer (spring)-3/8" I. D. x
9/16" O. D.
LA, LE
53-55
LA-2905 A
Hose (reservoir to booster tube
23" approx. length
LA, LE
53-55
353806-S8
Clip-hose to dash panel
LA, LE
53-55
31527-S7
Screw (washer head)-No. -14-
14 x 1/2"
LA, LE
53-55
1
1C-18572-A
Clamp-hose to reservoir to
booster tube & hose to power
brake
LA, LE
53-55
1C-18572-A
Clamp-hose to intake manifold to
brake booster tube
LA, LE
53-55
1C-18572-A
Clamp (hose-front)-booster to
reservoir tube
LA, LE
53-55
FDL-22004-A
K t (vacuum brake pump
LA, LE
53-55
