HDK-22005-F
Kit (power brake conversion)-
consists of the following
(1) LA-2005-C Booster (1) LA-2063-C Rsvr.
(1) LA-2076-A
Fitting (1) 91T-2154-A Gskt.
(1)91T-2276
Bolt
(2) 91A-2279
Clip
(1) LA-2455-G Pedal
(2) LA-2466-A Link
(1) LA-2482-B Shaft
(1) LA-2514-A Lever
(2) LA-2905-A Hose
(6) 1C-18572-A Clamp
(1) LA-22027-B Brkt.
(1) LA-22035-A Gskt.
(1) LA-22121-A Gasket (1) LA-22139-B Shield
(1) LA-22142-A Insulator (1) LA-22264-B
Hose
(1) LA-22270-A Tube
(1) LA-22349-A Tube
(2) LA-22515-A Bushing (1) LA-22519-A
Brkt.
(4) LA-22521-A Bushing (1) LA-22907-B
Tube
(1) 20326-57
Bolt
(4) 24347-S8
Bolt
(8) 24387-S8
Bolt
(1) 31527-S7
Screw
(1) 32858-S2
Screw
(4) 33798-S8
Nut
(1) 33802-S8
Nut
(1) 34053-S8
Nut
(6) 40143-S8
Screw
(2) 72035-S7-8 Pin
(1) 351022-S2
Nut
(1) 352601-S8
Bolt
(2) 352602-S8
Pin
(1) 353806-S8
Clip
(2) 356363-S7
Washer (1) 356746-S
Screw
(1) 357601-S32
Clip
(9) 357624-S7
L, hr.
LA
53-54
(1) 357639-S Elbow
LA-22027-B
Bracket assy (brake booster
mounting)-with pear shaped
hole
LA, LE
53-55
24387-S7
Bolt (hex-hd)-5/16"-24 x 1"
brkt. assy to brake pedal
support
LA, LE
53-55
24387-S7
Bolt (hex-hd)-5/16"-24 x "
power brake unit to
mounting bracket
LA, LE
53-55
357624-S7
Lockwasher (special)-5/16"-
mounting bracket to pedal
support brace
LA, LE
53-55
357624-S7
Lockwasher (special)-5/16"-
booster to mounting brkt.
LA, LE
53-55
355960-S
Nut (grommet)-5/16"'-24
LA, LE
53-55
LA-22035-A
Gasket (brake booster mounting
bracket)
LA, LE
53-55
LA-22120-B
Adapter (brake booster mounting)
-pear shaped holes
LA, LE
53-55
$LA-22121-A
Gasket (brake master cyl.
mounting adapter)
LA, LE
53-55
LA-22139-B
Shield (brake master cyl. heat
LA, LE
53-55
34053-S8
Nut (hex)-No. 10-24-heat
shield to booster
LA, LE
53-55
32858-S2
Screw (rd-hd)-tapping-No. 8-
15x1/2"
LA, LE
53-55
356746-S
Screw (fillister head)-No. 10-
24 x 3/4"-heat shield to
booster
LA, LE
53-55
LA-22142-A
Insulator (brake master cylinder
heat shield)
LA, LE
53-55
