Kits
LA-22157-A
Fitting (brake master cylinder
reservoir)-7/8"-14 x 15/32"
LA, LE
53-55
LA-22158-A
Plunger asst' (brake master cvl. )
LA, LE
53-55
352529-S
Washer (flat)-23/32" I. D. x
1-3/8" O. D. x 3/°2" thick
LA, LE
53-55
LA-22159-A
Retainer (brake master cyl.
plunger seal)-1-3/8" O. D.
LA, LE
53-55
NS LA-22160-A
Seal (brake master cyl. plunger)-
1-7/16" O. D. -serviced in
HDK-22160-B Kit
LA, LE
53-55
HDK-22160-B
Kit (gasket and seal repair)-
consists of the following
(1) LA- 2152-A Gasket (1) 91A-2167
Gasket
(1) LA-2178-B Valve (1) LA-2180-A Boot
(1) LA-2384 -A Seal
(1) 59T-2437
Seal
(1) LA- 2440-A Collar (1)TFAF-2493-A Seal
(1) LA- 22160-A Seal
(1)
LA-22161-A Washer
(1) LA-22162-A Ring (1) LA-22163-A Gasket
(1) LA-22164-A Spring (1)
LA-22165-A Retnr.
(1) LA-22354-A Stem (1) LA-22359-A Screen
(1) LA-22360-A Insul. (1) LA-22362-A S/Ring
(1) LA-22372-B Ball
(1) LA-22376-A Gasket
(1) LA- 22377-A Gasket (1) LA-22378-A Gasket
(1) LA-22379-A Gasket (1) LA-22383-A Washer
(1) LA-22384-A Gasket (1) LA-22493-A Gasket
LA, LE
53-55
14S LA-22161-A
Washer (brake master cylinder
plunger seal backing)-21/32"
I. D. x 1-3/8" O. D. -serviced
in HDK-22160-B Kit
LA, LE
53-55
NS LA-22162-A
Snap ring (brake master cylinder
plunger retaining)-serviced in
HDK-22160-B Kit
LA, LE
53-55
NS LA-22163-A
Gasket (brake master cylinder
reservoir cover)-Neoprene
serviced in HDK -22160-B Kit
LA, LE
53-55
NS LA-22164-A
Spring (brake master cylinder
compensating port)-9/16" at
large end-serviced in
HDK-22160-B Kit
LA, LE
53-55
NS LA-22165-A
Retainer (brake master cyl.
compensating port spring)
serviced in HDK-22160-B Kit
LA, LE
53-55
LA-22166-A
Cover asst' (brake master cyl.
reservoir)
LA, LE
53-55
352528-S8
Screw (pan head)-No. 10-24 x
7/16"
LA, LE
53-55
NS
LA-22167-A
Gasket (brake booster body
piston to hose tube plate)
Fibre-serviced in
HDK-22167-B & HEK-22167-A
LA, LE
53-55
