HDK-22167-B
Kit (piston packing)-consists of
the following
(1) 59T-2348
Wick (1) LA-2356-A Packing
(1) LA-2357-A Ring (1) LA-22167-A Gasket
(1) LA-22356-B Diaph. (1) LA-22365-A Gasket
1
LA
53
(1) LA-22381-A Hose
HEK-22167-A
Kit (piston backing)-consists of
the following
(1) 59T-2348
Wick (1) LA-2356-A
Packing
(1) LA-2357-A Ring (1) LA-22167-A Gasket
(1) LA-22356-C Diaph. (1) LA-22365-A
Gasket
1
LA, LE
54-55
(1) LA-22381-A Hose
N
S
LA-22249-A
Hose (reservoir to booster)-
8-1/2"-cut from LA-2905-A
2
LA, LE
53-55
LA-22264-B
Hose assy (brake master cyl.
to
connector)-approx. 25-3/8"
long
1
LA
53-54
MB-22264-B
Hose assy (brake master cvl.
to
connector)-approx. 16-19/32"
long
1
LE
55
LA-22270-A
Tube (booster to reservoir-front)
-1/2" O. D. x 9"
1
LA, LE
53-55
1352223-532 Clip (hose to front fender
apron)
1
LA, LE
53-55
$353806-S8
Clip (tube assv)-brake resvr.
to dash panel
1
LA. LE
52-55
131527-57
Screw (hex washer head self
tapping)-No. 14-14 x 1/2"
1
LA, LE
52-55
LA-22327-A
Retainer (brake booster body
piston return spring)-3-1/8"
O. D.
1
LA, LE
53-55
LA-22349-A
Tube assy (intake manifold to
brake booster)-approx.
10-41/64" formed length
1
LA, LE
53-55
20326-S7
Bolt (hex)-5/16"-18 x 5/8"-
357601-S32 to accelerator
shaft
1
LA, LE
53-55
357601-S32
Clip-tube to accelerator brkt.
1
LA, LE
53-55
357639-S
Elbow-1/2" x 7/16"-24 x 3/4"-
18-tube to intake manifold
1
LA, LE
53-55
87947-S7
Nut (connector)-3/4"-18
1
LA, LE
53-55
LA-22350-A
Hose (brake reservoir outlet)-
approx. 3-1/2" overall length
1
LA
53-54
N
S
LA-22350-C
Hose (reservoir to booster)-
4-1/2" annrox. overall lenath
cut from LA-2905-A
1
LA, LE
53-55
1C-18572-A
Clamp (hose)-reservoir outlet to
booster tube
2
LA, LE
53-55
N
S
LA-22354-A
Stem assy (brake master cylinder
compensating port valve)
serviced in HDK-22160-B Kit
1
LA, LE
53-55
