N` LA-22356-B
Diaph. assy (brake booster body)-
serviced in HDK-22167-B Kit
LA
53
N, LA-22356-C
Diaph. assy (brake booster body)-
serviced in HEK-22167-A Kit
1
LA, LE
54-55
LA-22358-A
Spring (brake booster body piston
reaction)-3-13/16" large end
1
LA, LE
53-55
N` LA-22359-A
Screen (brake booster plunger)-
serviced in HDK-22160-B Kit
1
LA, LE
53-55
N' LA-22360-A
Insulator (brake booster body
piston)-Rubber-2" O. D. -
serviced in HDK-22160-B Kit
1
LA, LE
53-55
352530-S8
Washer (flat)-1-5/16" I. D. x
2" O. D. x 3/64" thick
1
LA, LE
53-55
LA-22362-A
Snap ring (brake booster plunger
retaining)-serviced in
HDK-22160-B Kit
1
LA, LE
53-55
` LA-22365-A
Gasket (brake booster body
diaphragm)-5-1/8" I. D. x
5-7/8" O. D. -serviced in
HDK-22167-B & HEK-22167-A
Kits
1
LA, LE
53-55
LA-22368-A
Body asst' (brake booster check
valve)
1
LA, LE
53-55
40254-S2
Screw (fillister head)-No. 8-32
x 3/8" long
2
LA, LE
53-55
LA-22370-A
Cover asst' (b ake booster check
valve)
1
LA, LE
53-55
LA-22371-A
Spring (brake booster check valve
1
LA, LE
53-55
` LA-22372-B
Ball (brake booster check valve)-
Rubber-serviced in
HDK-22160-B Kit
1
LA, LE
53-55
` LA-22376-A
Gasket (brake booster check valve
49/64" I. D. x 29/32" O. D. -
serviced in HDK-22160-B Kit
1
LA, LE
53-55
` LA-22377-A
Gasket (brake booster check vale=
to hose tube brace)-(1) 17/32"
diameter hole-serviced in
HDK-22160-B Kit
1
LA, LE
53-55
N` LA-22378-A
Gasket (brake booster air cleaner
screw)-serviced in
HDK-22160-B Kit
1
LA, LE
53-55
` LA-22379-A
Gasket (brake booster body end
plate)-6" I. D. -serviced in
HDK-22160-B Kit
1
LA, LE
53-55
LA-22380-A
Plate (brake booster body end)-
6-3/4" O. D.
1
LA, LE
53-55
LA-22381-A
Hose (brake booster check valve
tube to body piston tube)-3/4"
O.D.-serviced in HDK-22167-B
and HEK-22167-A Kits
1
LA, LE
53-55
LA-22382-A
Cover (brake booster air cleaner
1
LA, LE
53-55
352527-S8
Screw (rd-hd)-No. 8-15 x 1/2"
long-to attach air cleaner to
body
1
LA, LE
53-55
