NS LA-22383-A
Washer (brake master cyl. boot)-
5/16" I. D. x 2-1/8" O. D. -
serviced in HDK-22160-B Kit
1
LA, LE
53-55
NS LA-22384-A
Gasket (brake booster air cleaner)
2
LA. LE
53-55
-3-3/8" long-serviced in
HDK-22160-B Kit
LA-22393-A
Tube asst' (brake booster body
piston to hose)
1
LA, LE
53-55
LA-22395-B
Plate (brake booster body piston)-
front
1
LA, LE
53-55
352526-S8
Screw (fillister head)-No. 8-32
x 1/2" long
8
LA, LE
53-55
NS LA-22493-A
Gasket (brake booster body to
master cylinder)-serviced in
HDK-22160-B Kit
1
LA, LE
53-55
20324-S8
Bolt (hex-hd)-1/4"-20 x 5/8"
3
LA, LE
53-55
34805-S7
Lockwasher-1/4"
3
LA, LE
53-55
LA-22515-A
Bushing (brake master cylinder
operating lever)-Nylon-1/2"
I. D. x 9/16" O. D.
2
LA, LE
53-55
LA-22519-A
Bracket (brake master cylinder
operating lever)
1
LA
53-54
LE-22519-A
Bracket (brake master cylinder
operating
1
LE
55
24347-S8
Bolt (hex-hd)-5/16"-24 x 3/4"
-lever brkt. to brake support
4
LA, LE
53-55
357624-S7
Lockwasher-5/16" -bracket to
pedal support brace
2
LA, LE
53-55
33798-S8
Nut (hex)-5/16"-24
4
LA, LE
53-55
LA-22521-A
Bushing (brake pedal lever)-3/8"
I. D. x 7/16" O. D. x 11/64"
long
4
LA, LE
53-55
LA-22907-A
Tube (brake reservoir to booster)
-23-41/64" long x 4-1/4" wide
use with LA-2063-B reservoir
tank only
1
LA
53-54
LA-22907-B
Tube (brake reservoir to booster)
-23-41/64" long x 3-7/8" wide
use with LA-2063-C reservoir
tank only
1
LA
54
LE-22907-A
Hose (brake reservoir to booster)
-44" long-NOTE all hose cut
previously from LA-2905-A
will be cut from above part
1
LE
55
40143-S8
Screw (hex-hd)-5/16"-18 x
1/2"-tube to frame assy
2
LA. LE
53-55
