-A
Control assembly (hand brake)
LA
52
-B
Control assembly (hand brake)
1
LA, LE
52-55
NS LA-22797-A
Anti-squeak (parking brake brkt.)
-2" x 1-1/4"-impregnated web
bing-secure locally
LA, LE
52-55
24327-S7
Bolt (hex head)-5/16"-24 x
5/8"-hand brake control to
dash panel
LA, LE
52-55
34826-S7
Lockwasher- 5/16" -hand brake
control to dash panel
LA, LE
52-55
42905-S8
Screw & lockwasher assy (hex
head)-5/16"-24 x 3/4"-hand
brake control mounting to
instrument panel
LA, LE
52-55
44722-S8
Washer (flat)-5/16"-hand
brake control mounting to
instrument panel
LA, LE
52-55
Retainer (ratchet bar locking spring)
LA, LE
52-55
Spring (ratchet bar locking)-outer
LA, LE
52-55
Pulley asst' (hand brake cable)
LA, LE
52-55
73880-S8
Pin (clevis)-5/16" x 13/16"
1
LA, LE
52-55
352358-S
Pin (self locking)-9/32" x
61/64"-used with 73880-S8
LA. LE
52-55
-A
Clip (hand brake cable spring lock)-1-3/32"
wide
at closed end
LA, LE
52-55
-A
Clip (hand brake cable spring lock)-13/16"
wide
at closed end
LA, LE
52-55
Clip (hand brake cable spring lock)
LA, LE
52-55
Pin (hand brake handle locking)-straight
knurled-
5/32" diameter x 13/32" overall
length
LA, LE
52-55
-A
Cable and conduit asst' (hand brake)-front-
65-13/16" long
LA, LE
52-55
31498-S8
Screw (hex washer head)-
No. 14-10 x 5/8"-cable and
conduit assy to dash panel
LA, LE
52-55
Pin (hand brake lever)-straight knurled-9/32"
dia.
x 15/16" overall length
LA, LE
52-55
-A
Clip (hand brake cable)-1-1/2" long
with two
23/64" holes
LA. LE
52-55
41170-S8
Screw (hex-hd)-5/16"-18 x
3/8"-clip to rear bracket
4
LA, LE
52-55
-B
Compressor assy (air conditioning)
LA60-73
53
-B
Compresses asst' (air conditioning)
1
LA60-73
54
-B
Compressor asst' (air conditioning)
1
LE60-73
55
620368-S8
Bolt (hex-hd)-3/8"-16 x 7/8"-
mounting brkt. to
air
compressor assy
LA, LE60-73
54-55
020410-S8
Bolt (hex-hd)-7/16"-14 x
1-1/8"-compressor to
generator brkt.
LA60-73
53
020428-S8
Bolt (hex-hd)-bracket to
compressor
LA60-73
54
0354135-S8
Bolt (hex-hd)-3/8"-16 x 1-1/8"
-compressor to cyl. block
LA60-73
53-54
