HCK 3047-A
Kit (front suspension upper shaft)-consists of the
following
(1) LA-3056-C Shaft
(2) LA-3068-A Bushing
(2) B4A-3091-A Washer (2) 357628-S7 L/Washer
(2) 33850-S Nut
LA
52-53
HCK 3047-B
Kit (front suspension upper shaft)-consists of the
following
(1) LA-3056-D Shaft
(1) LA-3068-A Bushing
(1) B4A-3087-B Bushing (1) B4A-3090-A Washer
(2) B4A-3091-A Washer (2) 33850-S8
Nut
(2) 357628-S8 Lockwasher
LA
54
HCK 3047-C
Kit (front suspension upper shaft)-consists of the
following
(1) LA-3056-D Shaft
(1) LA-3068-A Bushing
(1) B4A-3087-B Bushing (1) B4A-3090-A Washer
(2) B4A-3091-B Washer (2) 33850-58
Nut
(2) 357628-S8 Lockwasher
LA, LE
54-55
HCK 3049-B
Kit (front suspension arm joint-upper)-consists o
the following
(1) LA-33046-A Joint
(1) LA-33055-A Cover
(1) LA-33056-A Shield (1) LA-33057-B Seal
(1) LA-33058-A Retainer (1) 34033 -S18 Nut
(1) 72035-S8 Cotter pin
LA, LE
52-55
HCK 3050-B
Kit (front suspension arm joint-lower)-consists o
the following
(1) LA-33057-B Seal
(1) LA-33059-A Joint assy
(1) LA-33068-A Cover (1) LA-33069-A Retainer
(1) 34034-S18 Nut
(1) 72054-S
C/Pin
LA
52-54
HCK 3050-C
Kit (front suspension arm joint-lower)-consists of
the following
(1) LA-33057-B Cover (1) LA-33059-B Joint assy
(1) LA-33068-A Cover (1) LA-33069-A Retainer
(1) 34034-S18
Nut
(1) 72054-S
C/Pin
LA, LE
54-55
LA 3054-A
Shim (front suspension lower arm front mounting
bolt)-56/64" I. D. x 1-3/4" 0. D. x 1/16" thick-
also serviced in HDK-3055-B & HDK-3057-A &
B Kits
as
reqd
LA, LE
52-55
LA 3054-B
Shim (front suspension lower arm front mounting
bolt)-57/64" I. D. x 1-3/4" 0. D. x 1/8" thick-
also serviced in HDK-3055-B & HDK-3057-A &
B Kits
as
regd
LA, LE
52-55
LA 3055-A
Bolt (front suspension lower arm rear mounting)-
5/8"-18 x 5-7/8" long-also serviced in
HDK-3055-B Kit
LA, LE
52-55
HDK 3055-A
Kit (front suspension lower arm rear mounting)-
consists of the following
(2) LA-3054-A Shim
(2) LA-3054-B Shim
(1) LA-3055-A Bolt
(1) LA-3069-A Bushing
(1) LA-3085-A Seat
(1) B4A-3091-A Washer
(1) 33800-S2
Nut
(1) 357628-S7
1,AVasher
LA
52-54
HDK 3055-B
Kit (front suspension lower arm rear mounting)-
consists of the following
(2) LA-3054-A Shim
(2) LA-3054-B Shim
(1) LA-3055-A Bolt
(1) B4A-3069-C Bushing
(1) LA-3085-A Seat
(1) LA-33094-AWasher
(1) 33850-S2
Nut
(1) 357628-S7 L/Washer
LA, LE
54-55
LA-3056-C
Shaft (front suspension upper arm)-inner-14-7/16"
overall length-also serviced in HCK-3047-A Kit
LA
52-53
