LA 3105-A
Spindle assy (front wheel)-includes nut
2
1 LA, LE
1 52-55
LA 3105-B
Spindle assy (front wheel)-heavy duty-includes
nut-
also serviced in HDK-66005-A & B Kits
2
LA, LE
53-55
72035-S7-8
Cotter pin-1/8" x 1"-shaft
assy to spindle assy
2
LA, LE
52-55
72054-S Cotter pin-5/32" x 1-1/4"
2
LA, LE
52-55
34634-S18
Nut (hex slotted)-5/8"-18
LA, LE
52-55
357498-S
Nut (hex slotted)-3/4"-16
LA, LE
52-55
LA 3130-B
Arm (spindle steering)-R. H.
LA, LE
52-55
LA 3130-C
Arm (steering spindle-heavy duty)-R.
H. -also
serviced in HDK-66005-A & B Kits
1
LA, LE
53-55
LA 3131-B
Arm (spindle steering)-L. H.
LA, LE
52-55
LA 3131-C
Arm (steering spindle-heavy duty)-L.
H. -also
serviced in HDK-66005-A & B Kits
LA, LE
53-55
357164-S8
Bolt (hex head)-1/2"-20 x
2-13/32"-lower spindle
LA, LE
52-55
72035-S7-8
Cotter pin-1/8" x 1"-lower
spindle
LA, LE
52-55
357625-S7
Lockwasher-7/16"
LA, LE
52-55
34032-S7
Nut (castle)-1/2"-20-lower
spindle
LA, LE
52-55
LA-33046-A
Joint assy (front suspension upper
arm ball)-also serviced in
HCK-3049-B Kit
LA, LE
52-55
350711-S8
Bolt (hex head)-3/8"-24 x 2"-
ball joint to upper arm
LA, LE
52-55
72035-S7
Cotter pin-1/8" x 1"-ball
joint to spindle
LA, LE
52-55
87901-S8
Fitting (lubricator)-1/8"-27-
straight type
LA, LE
52-55
357629-S7
Lockwasher-3/8"-ball joint to
upper arm
LA, LE
52-55
33800-S8
Nut (hex)-3/8"-24-ball joint to
upper arm
LA, LE
52-55
34033-S18
Nut (hex-castle)-9/16"-18-ball
joint to spindle
LA, LE
52-55
LA-33055-A
Cover (front suspension upper
arm ball joint dust)-2" O. D. -
with oblong hole 57/64"
across flats-also serviced in
HCK-3049-B Kit
LA, LE
52-55
LA-33056-A
Shield (front suspension upper
arm ball joint dust)-1-13/16"
0. D. x 47/64" 1. D. x 15/32"
thick-also serviced in
HCK-3049-B Kit
LA, LE
52-55
LA-33057-B
Seal (front suspension upper arm
ball joint dust)-45/64" I. D. x
1-3/4" O. D. x 11/32" thick
also serviced in HCK-3049-B
& HCK-3050-B & C Kits
LA, LE
52-55
LA-33058-A
Retainer (front suspension upper
arm ball joint dust seal)-1
3/4" O. D. x 47/64" 1. D. x
23/64" thick-also serviced in
HCK-3049-B Kit
LA, LE
52-55
