351059-S Nut (hex slotted)-1/2
LA-33059-A
oint assy (front suspension
lower arm ball)-also serviced
in HCK-3050-B Kit
LA
52-54
LA-33059-B
oint assy (front suspension
lower arm ball)-also serviced
in HCK-3050-C Kit
LE
55
350708-S8
Bolt (hex head)-1/2"-20 x 2-
37/64"-ball joint to lower
arm
LA, LE
52-55
72054-S Cotter pin-5/32" x 1-1/4' -
ball joint to spindle
LA, LE
52-55
87901-S8
Fitting (lubricator)-1/8"-27-
straight type
LA, LE
52-55
_
357626-57
Lockwasher-1/2" -ball joint to
lower arm
LA, LE
52-55
33846-S8
Nut (hex)-1/2"-20-ball joint
to lower arm
LA, LE
52-55
34034-S18
Nut (hex slotted)-5/8"-18-ball
joint to spindle
LA, LE
_
52-55
_
LA-33068-A
Cover (front suspension lower
arm ball joint dust)-2-1/8"
0. D. x 57/64" 1. D. x 15/32"
thick-also serviced in
HCK-3050-B & C Kits
LA, LE
52-55
LA-33069-A
Retainer (front suspension lower
arm ball joint dust seal)
57/64" I. D. x 1-3/4" O. D. x
19/64" thick-also serviced in
HCK-3050-B & C Kits
LA, LE
52-55
_
LA-33072-A
Bolt (front suspension upper arm
mounting)-9/16"-18 x 2-39/64"
-to attach upper arm and shaft
to upper bracket
LA, LE
52-55
_
357627-S7
Lockwasher-9/16"-arm &
shaft to bracket
LA, LE
52-55
33848-S7
Nut (hex)-9/16"-18-upper arm
to bracket
LA, LE
52-55
_
LA-33094-A
Washer (front suspension lower
arm bushing compression)
rear-also serviced in
HDK-3055-B Kit
LA, LE
52-55
LA-33590-A
Stop (steering arm)-R. H.
LA, LE
52-55
LA-33591-A
Stop (steering arm)-L. H.
LA, LE
52-55
Steering Linkage
HACK 3270-A
Kit (steering spindle connecting rod end)-consists
of the following
(1) LA-3289-A End assy (1) 8M-3332
Seal
(1) 72035-S7
C/Pin
(1) 351059-S8 Nut
(1) 87924-S8 Fitting
2
LA, LE
52-55
LA 3280-B
Rod and ball stud assy (steering spindle arm
connecting)
2
LA, LE
52-55
72035-S7-8
Cotter pin-1/8" x 1"
2
LA, LE
52-55
87924-S8
Fitting (lubricator)1/4"-28 x
1/2"-elbow type
2
LA. LE
52-55
_
LA, LE
52-55
