_gear
LA-3504-E
Gear assy (steering)-less tube &
flange
LA
53
LA-3504-G
Gear assy (steering)-less tube &
flange-without center brg.
LA
54
LE-3504-B
Gear assy (steering)-less tube &
flange
LE
55
353431-S8
Bolt (hex)-7/16" -14 x 4-3/8"-
assy to frame
LA, L
53-55
351989-S8
Bolt (hex)-7/16"-14 x 4-5/8"-
,ear assy to frame
LA, L
53-55
FAB-3507-B
Clamp (steering column)-2-1/2"
I. D. -3/8" clamping bolt
LA
53
FDD-3507-A
Clamp (steering column)-2-1/2"
I. D. - 7/16" clamping bolt
LA
54
FDL-3507-A
Clamp(steering column)-2-15/32"
I. D.
LE
55
353117-58
Bolt (carriage)-7/16"-20 x 2"
clamp to tube assembly
LA
54
_
358478-58
Bolt (carriage)-7/16"-20 x
2-1/8"
LE
55
24389-S8
Bolt (hex-hd)-3/8"-24 x 7/8"
LA
53
34807-S2
Lockwasher-3/8"
1
LA
53
34808-S8
Lockwasher-7/16"
1
LA, LE
54-55
33800-S8
Nut (hex)-3/8"-24
1
LA
53
33802-S8
Nut (hex)-7/16"-20
1
LA
54
353388-S8
N t (hex lock)-7/16"-20
LE
55
FAC-3509-A
Flange & bearing assy (steering
column tube)-use with
FAD-7200-AP
LA
53-54
FDL-3509-A
Flange & bearing assy (steering
column tube)
LE
55
FAC-3514-AP
Tube assy (steering column)-in
Prime-31-35/64" approx.
overall length
LA
53-54
FDL-3514-DP
Tub assy (steering column)-in
Prime-31-25/64" approx.
overall length
LE
55
FAA-3517-A
Bushing (steering column)-upper-
1-7/16" O. D.
LA, LE
52-55
LA-3517-A
Bearing assy (strg. gear shaft)-
1-1/4" I. D. x 1-5/8" O. D.
LA
53-54
LA-3524-B
Shaft & worm assy (steering gear
LA, LE
53-55
LA-3548-D
Housing assy (steering gear)
LA
53-54
LA-3548-E
Housing assy (steering gear)
LA, LE
54-55
92039-S Screw (round head)-No. 6-to
seal inspection hole
-LA
53
