D.
PART
NUMBER
PART NAME
8L-4209-A
Ring gear & pinion (rear axle)-matched set 3. 91 to 1 ratio
8L 4209-D
Ring gear & pinion (rear axle)-matched set 3. 31 to 1 ratio
8L 4209-F
Ring gear & pinion (rear axle)-matched set 4. 27 to 1 ratio
LA 4209-C
Ring gear & pinion (rear axle)-matched set 3. 15 to 1 ratio
LA 4209-D
Ring gear & pinion (rear axle)-matched set-3. 07 to 1 ratio
353596-S
Bolt (hex head)-7/16"-20 x 7/8"
356597-S
Plate (locking)-ring gear to differential case
8L 4211
Shaft (differential pinion)
8M 4215
Pinion (differential)-small-10 teeth
8L 4221
Cone & roller assembly (rear axle differential)
8L 4222
Cup (rear axle differential bearing)
8L 4228
Washer (differential gear thrust)
8M 4230
Washer (differential pinion thrust)
LA 4234-B
Shaft & bearing assy (rear axle)-30-1/16" from inside of
flange to end of spline
a LA 4234-E
Shaft & bearing assy (rear axle)-29-1/8" from inside of
flange to end of spline-1954 models only
6 LA 4234-H
Shaft & bearing assy (rear axle)-29-39/64" from inside of flange
to end of spline
+LA-1107-A
Bolt (rd-hd-spec.)-1/2"-20 x 1-5/16"-rear axle
shaft to drum
8M-1180 Retainer (rear wheel brg. )-inner-1-17/32" I. D.
x 2-1/8" O. D. x 3/8" thick
8M-1225-B Bearing (rear wheel)-1-17/32" I. D. x 3-5/32" O.
8M-2240 Retainer (rear wheel brg. )-2-1/4" I. D. x 4-3/8"
wide
a8M-2248
Bolt (spec-hd)-1/2"-20 x 1-1/8"-rear axle brake
housing
34424-57 Locknut (hex)-1/2"-20
8L 4236
Gear (differential side)-large-16 teeth-20 splines
