HFK-6008-A
Kit (engine overhaul gasket)-consists of the
following
(1) EAD-6020-B Gasket (2) EBJ-6051-C Gasket
(1) LE-6411-A Seal
(1) B4A-6436-A Seal
(1) EAD-6521-A Gasket (4) B4A-6570-A Seal
(16) EAA-6571-C Seal
(2) EAD-6584-B Gasket
(1) EAD-6619-A Gasket (1) B4A-6625-A Gasket
(1) B4A-6643-A Seal
(1) B4A-6648-A Gasket
(1) B4Q-6659-A Gasket (1) EAD-6668-B Furrell
(1) 8EL-6669
Gasket (1) B4A-6698-A Seal
(1) EAA-6700-B Seal
(2) B4Q-6701-A Seal
(2) EAD-6702-B Seal
(1) B4Q-6710-A Gasket
(1) 86H-6734
Gasket (1) EAD-6870-A Gasket
(1) B4A-6872-A Gasket (1) EAD-8255-A Gasket
(1) EAD-8507-A Gasket (1) EAD-8563-B Gasket
(1) EAD-8590-B Gasket (1) EAD-9417-A Gasket
(2) EAD-9441-B Gasket (2) B2Q-9450-A Gasket
(1) LA-9453-A Gasket
LE
55
&EAD 6009-D
NS Cylinder assembly-replaced by EAD-6009-E
LA
52
&EAD 6009-E
Cylinder assembly
LA
52-53
&EAD 6009-J
Cylinder assembly
1
LA
54
& EBJ 6009-A
Cylinder assembly
LE
55
EAD 6010-D
Block assembly (cylinder)-includes LA-6394-C
LA
52-53
EAD 6010-F
Block assembly (cylinder)-includes LA-6394-C
1
LA
54
EBJ 6010-B
Block assembly (cylinder)
1
LE
55
9N-8115-B
Cock assy (drain)-straight type
LA, LE
52-55
B2Q-6061-A
Dowel (cyl. head to cyl. block)-
(DEAD-66061-A
LA, LE
52-55
43153-S Bolt (hex head)-9/16"-12 x
3-1/4"-bearing caps to
cylinder block
10
LA, LE
52-55
87837-S Plug (drain)-1/4"-18-cylinder
block oil pipe-tappet gallery
lines-right rear only
LA, LE
52-55
87838-S8
Plug (drain)-3/8"-18-cylinder
block main oil line gallery
rear outer
LA, LE
52-55
353055-S7
Plug (external head pipe)-1/4"-
18 x 3/4"-cyl. block oil lines
LA
52-54
357217-S
Plug (expansion)-1-49/64"O. D.
LA, LE
52-55
357477-S
Plug (expansion)-37/64"O. D.
1
LA, LE
52-55
357565-S
Plug (expansion)-61/64"O. D.
1
LA, LE
52-55
352996-S100 Plug (headless hex socket-dry
seal)-1/4"-18 pipe thread
cyl. block oil pipe-tappet
LA, LE
52-55
