EAD 6005-G
Engine assy-less transmission
LA
_
_ 54 J
EBJ 6005-A
Engine assy-less transmission
LE
55
HDK-66005-A
Kit (heavy duty detail)-3. 92 to 1
rear axle ratio-consists of the
following
(2)
LA-3105-B
Spindle assembly
(1)
LA-3130-C
Arm (strg. spindle)-R. H.
(1)
LA-3131-C
Arm (strg. spindle)-L. H.
(1)
8L-4205-A
Case (diff. gear)
(1)
8L-4209-A
Ring gear & pinion
(1)
LA-5482-B
Bar assembly
(1) EAD-6250-E
Camshaft
(16) EAM-6500-C Tappet assembly
(16) EAA-6565-C
Rod (valve push)
(1) EAD-8600-B
Blade assembly (fan)
(2) EAD-9441-Y
Gasket (inta~e manifold)
(1)
LA-17322-B Gear assy (speedometer)
(2)
LA-18045-E Shock absorber (front)
(2)
LA-18080-E Shock absorber (rear)
LA, LE
53-55
HDK-66005-B
Kit (heavy duty detail)-4. 27 to 1
rear axle ratio-consists of the
following
LA, LE
53-55
(2)
LA-3105-B
Spindle assembly
(1)
LA-3130-C
Arm (strg. spindle)-R. H.
(1)
LA-3131-C
Arm (strg. spindle)-L. H.
(1)
8L-4205-A
Case (diff. gear)
(1)
8L-4209-F
Ring gear & pinion
(1)
LA-5482-B
Bar assembly
(1) EAD-6250-E
Camshaft
(16) EAM-6500-C Tappet assembly
(16) EAA-6565-C
Rod (valve push)
(1) EAD-8600-B
Blade assembly (fan)
(2) EAD-9441-Y
Gasket (intake manifold)
(1)
LA-17322-B Gear assy (speedometer)
(2)
LA-18045-E Shock absorber (front)
(2)
LA-18080-E Shock absorber (rear)
HEK 6008-D
Kit (engine overhaul gasket)-consists of the
following
(1) EAD-6020-B Gasket (2) EAD-6051-B Gasket
(1) EAD-6377-A Gasket (1) LA-6411-B Seal
(1) EAD-6436-A Seal
(1) EAD-6521-A Gasket
(4) B4A-6570-A Seal
(16) EAA-6571-A Seal
(2) EAD-6584-B Gasket (1) EAD-6619-A Gasket
(1) B4A-6625-A Gasket (1) EAD-6648-B Gasket
(1) B4Q-6659-A Gasket , (1) B4A-6643-A Seal
(1) EAD-6668-B Ferrule
(1) 8EL-6669
Gasket (1) EAA-6700-B Seal
(2) B4Q-6701-A Seal
(2) EAD-6702-B Seal
(1) B4Q-6710-A Gasket (1) 86H-6734' Gasket
(1) EAD-6870-A Gasket (1) B4A-6872-A Gasket
(1) EAD-8255-A Gasket (1) EAD-8507-A Gasket
(1) EAD-8563-B Gasket (1) B4Q-8590-A Gasket
(1) EAD-9417-A Gasket (2) EAD-9441-B Gasket
(2) B2Q-9450-A Gasket (1) LA-9453-A Gasket
LA
52-54
