LA 5482-B
Bar assy (front stabilizer)-also serviced in Heavy
Duty HDK-66005-A & B Kits
LA, LE
53-55
LA 5482-C
Bar assy (front stabilizer)
LA, LE
52-55
8L 5484
Bushing (stabilator to frame)-Rubber
LA, LE
52-55
8M 5486
Bracket (stabilator to frame)
LA, LE
52_-55 _
_
20389-S8
Bolt (hex-hd)-3/8"-24 x 1"-
stabilator bracket to frame
LA, LE
52-55
1
357629-S7
Lockwasher-3/8"
LA, LE
52-55
351009-S5
Nut (weld)-3/8"-24
LA, LE
54-55
LA 5490-A
Spacer (front stabilator bar)-35/64" O. D. x 27/64"
I. D. x 2-29/64" long-also serviced in
HDK-55495-A & B Kits
LA, LE
52-55
I AB-18031-A
Seat (front stabilizer insulator)
LA LE
54-55
8M-18041
Washer (front stabilizer insulator
LA
52-53
AB-18041-B
Washer (front stabilizer insulator
LA, LE
54-55
AB-18198-A
Insulator (front stabilizer bar to
suspension lower arm)-Rubber
LA, LE
54-55
LA-55495-A
Bolt (stabilator link)-5/16"-24 x
4-55/64"-also serviced in
HDK-55495-A & B Kits
LA, LE
52-55
33798-S8
Nut (hex)-5/16"-24
LA, LE
52-55
HDK-55495-A
Kit (stabilator link)-consists o
the following
(1) LA-5490-A Spacer (1) 8M-18031
Seat
optional with OA-18031-A
(1) OA-18031-A Seat-
(4) 8M-18041
Washer
optional with 8M-18031
(4) 8M-18198
Insulator(1) LA-55495-A Bolt
(1)
33798-S8
Nut
LA
52-53
1
HDK-55495-B
Kit (stabilator link)-consists o
the following
(1) LA-5490-A Spacer (1) AB-18031-A Seat
(4) AB-18041-B Washer (4) AB-18198-A Insulator
(1) LA-55495-A Bolt
(1)
33798-S8 Nut
2
LA, LE
54-55
Rear Spring, Hangers and Clips
* LA 5560-A
Spring assy (rear)-Standard-8 leaf-980 pound load
LA, LE except 76
52-55
LA 5560-B
Spring assy (rear)-Heavy Duty-9 leaf-1030 lb. load
-used on 60 & 73 models Heavy Duty for 1955
LA, LE
52-55
LA 5560-C
Spring assy (rear)-standard-8 leaf-1030 pound load
-used on 60 & 73 models Heavy Duty for 1955
LA76, LE
52-55
350321-S2
Bolt (special head-spring
center)-5/16"-24 x 2-7/8"
LA, LE
52-55
351656-S2
Bolt (spec-hd spring center)-
5/16"-24 x 3-1/4"
LA, LE
52-55
357626-S7
Lockwasher-1/2"-spring to
rear axle
LA, LE
52-55
33798-S8
Nut (hex)-5/16"-24
LA, LE
52-55
_
33846-S8
Nut (hex)-1/2"-20-spring to
rear axle
8
_
LA, LE
52-55
8M 5586
Insert assy (rear spring)-packaged 8 pieces to
carton-amount necessary for one rear spring
16
LA, LE
52-55
