8M 3332
Seal (steering linkage ball stud)-Rubber-also
serviced in HCK-3270-A Kit
LA, LE
_
52-55
_
LA 3343-B
Shield (steering connecting link extension
ball stud-
dust)
LA, LE
52-55
-
AD 3351-A
Bracket (steering idler arm mounting)-to
frame
LA, LE
52-55
45565-S8
Bolt (hex head)-3/8"-24 x 4"
2
LA, LE
52-55
357629-S7
Lockwasher-3/8"
2
LA, LE
52-55
33800-S8
Nut (hex)-3/8"-24
LA, LE
52-55_
HCK-3352-A
Kit (steering idler arm)-consists of
the following
(1) LA-3355-A Arm (2) MA-3356-A Bushing
(2) 8M-3359
Seal
(2) 87918-S8
Fitting
LA, LE
52-55
LA 3355-A NS
Arm (steering idler)-serviced in HCK-3352-A
Kit
LA, LE
52-55
358032-58
Fitting (lubricator)-1/8"-27 x
850
LA, LE
52-55
MA 3356-A NS
Bushing assy (steering idler arm)-serviced
in
HCK-3352-A Kit
LA, LE
52-55
8M 3359
Seal (steering idler arm)-Rubber-also
serviced in
HCK-3352-A Kit
LA, LE
52-55
f
Steering Gear
LA 3504-C
Gear assy (steering)-20. 4 to 1 ratio
LA, LE
52-55
t LA 3504-E
Gear assy (steering)-less tube &
flange-not used
with Air Conditioning
LA
53
t LA 3504-G
Gear assy (steering)-less tube &
flange
LA
53-54
LE 3504-B
Gear assy (steering)-less tube &
flange
LE
55
353431-58
Bolt (hex head)-7/16"-14 x -
3/8"-to frame
LA, LE
52-55
357625-S7
Lockwasher-7/16"-to frame
LA, LE
52-55
351428-S7
Washer (flat)-7/16"-to frame
LA, LE
52-55
AAA 3507-B
Clamp (steering column)-3/8" clamping
bolt
LA
52-53
tFAB 3507-B
Clamp (steering column)-2-1/2" I.
D.
LA
53
tFDD 3507-A
Clamp (steering column)-with 2 ears
LA
54
ADD 3507-B
Clamp (steering column)-7/16" clamping
bolt
LA, LE
54-55
FDL 3507-A
Clamp (steering column)-2-15/32"
I. D.
LE
55
358478
Bolt (carriage)-7/16"-20 x
2-1/8"
LE
55
353117-S8
Bolt (carriage)-7/16"-20 x "-
clamp to tube assy
LA
54
24521-S7
Bolt (hex-hd)-5/16"-32 x
1-7/8"
LA
52
34807-S8
Lockwasher-3/8"
LA
52-53
34808-S8
Lockwasher-7/16"
1
LA, LE
54-55
33800-S8
Nut (hex)-3/8"-24
1
LA
52-53
34671-S Nut (hex)-7/16"-20
1
LA
54
353388-58
Nut (hex lock)-7/16"-20
LE
55
