B5S-77162-A
Planet assy (transmission)-EPPMB-77162-A
1L-77163-A
Piston assy (transmission reverse clutch)
LA-77163-A
Piston assy (transmission reverse clutch)
1L-77164-A
Pin (transmission reverse blocker piston
stop)-
1/8" dia. x 1-5/161, long
HBK-77167-A
Kit (transmission reverse clutch piston
seals)-
consists of the following
(1) 1L-77167-A Seal-outer
(1) 1L-77174-A Seal-inner
NS
1L-77167-A
Seal (transmission reverse clutch piston)-outer
-serviced in HBK-77167-A Kit
8L-77170
Gear & Flange assy (transmission
reverse sun)
24466-S7
Bolt (hex-hd)-5/16"-18 x 1-1/2"-reverse
drive
flange to trans. rear drum & pin
assembly
34941-57
Lockwasher (external tooth)-5/16"-reverse
drive flange to trans. rear drum &
pin assy.
34906-S8
Lockwasher (internal tooth)-5/16"
NS
1L-77174-A
Seal (transmission reverse clutch piston)-inner
-serviced in HBK-77167-A Kit
1L-77179-A
Spacer (trans. reverse planet carrier)-
1-11/16"
O. D. x 1-25/64" I. D. x 23/64"
thick
OL-77180
Carrier assembly (trans. front planet)-complete
LA-77180-A
Carrier assembly (trans. front planet)-complete
8L-77184
Washer (trans. front planetary assy
front backing)
-Steel-1-11/32" I. D. x 1-13/16"
O. D. x 3/32"
thick
1L-77187-A
Drum assembly (transmission rear clutch)
